Vista 1 Digital Mixing System
2-54 Desk Operation
Document generated: 18.04.17
SW V5.3
Second Layer Disabled (Standard Vista Operation):
Section 2Section 1 Section 3
Section 4 Section 5 Section 6
Second Layer Enabled:
Section 2Section 1
L2
Switches
Section 3
Section 4 Section 5 Section 6
It is still possible to globally switch to the second layer by pressing the sec-
tion navigator keys 4…6. This will activate the ↓ L2 ↓ keys on each strip of
the console surface, indicating that the operator is now looking at the lower
half of the console.
Displaying Both Layers at the Same Time:
If the second layer option is activated, Vista 1 may display the label and real
time metering of both layers at the same time. In order to activate this label
view, press LABEL TYPE several times until the label display area on the
Vistonics screen shows the labels of both layers. This label of the second layer
appears only if there is a channel assigned to that strip on both layers. Use
the Strip Setup dialog on the Graphical Controller screen to do this.
Next to the label there is a small icon showing the level of the alternate layer
(below, left). When switched to the second layer, the label lines are swapped,
and the top line is showing the first layer label and metering (below, right).
Note: The second layer is displayed only if the first layer is not empty.
