ME310G1/ME910G1/ML865G1 AT Commands Reference Guide
80617ST10991A Rev.4 Page 297 of 545 2020-04-15
3.8.4. AT#SLED - STAT_LED GPIO Setting
The command configures the behavior of the STAT_LED status.
SIM Presence
Setting saved
Can be aborted
MAX timeout
SELINT
Not required
Other
No
-
2
AT#SLED=<mode>[,<onDuration>[,<offDuration>]]
STAT_LED is mapped on a GPIO for ME910G1 and ML865G1 families, but it is on a dedicated pin
for ME310G1 family.
To configure a GPIO pin as STAT_LED GPIO, the user must enter AT#GPIO=x,0,2 command to
set the GPIO_x pin as ALT1 alternate function. At the next power ON, the GPIO pin is low until the
control reads the saved setting in NVM and configures the GPIO_x as STAT_LED GPIO. Not all
GPIOs can be configured as STAT_LED pin. See #GPIO description to know the available GPIOs
for this function.
In case of a dedicated pin for STAT_LED function, there is no GPIO to set in ALT1 function.
Parameters:
Name
Type
Default
Description
<mode>
integer
N/A
defines the STAT_LED pin behavior.
"pin" indicates the GPIO or the dedicated pin according to
the family of modules used.
Family
<mode> default value
ME910G1
2
ML865G1
2
ME310G1
5
Values:
0
:
pin tied low
1
:
pin tied high
2
:
pin is handled with specific timings. See Additional info section
3
:
pin is turned ON/OFF alternatively, with period defined by the sum
<onDuration> + <offDuration>
4
:
pin is handled with specific timings. See Additional info section
5
:
status led disabled
<onDuration>
integer
10
duration of period in which STAT_LED pin is tied high
while <mode>=3
Value:
1÷100
:
in tenth of seconds
<offDuration>
integer
10
duration of period in which STAT_LED pin is tied low
while <mode>=3
Value:
1÷100
:
in tenth of seconds
Additional info:
