3.8.9. AT#I2CWR - Write to I2C
This command is used to send data to an I2C peripheral connected to module.
[1] Hardware User's Guide of the used module
SIM Presence
Setting saved
Can be aborted
MAX timeout
SELINT
Not required
No
No
-
2
AT#I2CWR=<sdaPin>,<sclPin>,<deviceId>,<registerId>,<len>
Execution command sends data to an I2C peripheral connected to module GPIOs. After the writing
activity has been accomplished, the GPIOs will not be restored to the original setting. Use #GPIO
command to see the status of the used GPIOs. To have information on GPIO pins refer to
document [1].
Parameters:
Name
Type
Default
Description
<sdaPin>
integer
-
GPIO number for SDA. To know the range use #I2CWR test
command.
<sclPin>
integer
-
GPIO number for SCL. To know the range use #I2CWR test
command.
<deviceId>
hex
N/A
address of the I2C device (7 bits). The Least Significant Bit
is used for read/write command, but in this #I2CWR
implementation, it doesn't matter if the LSB is set to 0 or 1.
Address must be written in hexadecimal form without 0x.
10 bit address is also supported.
Value:
0÷3FF
:
addressing range extended to 10 bit
<registerId>
hex
N/A
register to write data to
Value:
0÷FF
:
value must be written in hexadecimal form without 0x
<len>
integer
N/A
number of data to send
Value:
1÷254
:
number of data to send
Additional info:
After entering the command, the module returns the prompt ">" and waits for the data to
send. To complete the operation, send Ctrl-Z char (0x1A hex); to exit without writing the
message send ESC char (0x1B hex). Data must be written in hexadecimal form.
If data are successfully sent, the response is OK, otherwise an error code is reported.
