ME310G1/ME910G1/ML865G1 AT Commands Reference Guide
80617ST10991A Rev.4 Page 328 of 545 2020-04-15
Jamming Detection and Report
3.11.1. AT#JDRENH2 - Enhanced Jamming Detection and Report
This command enables/disable jamming detection, and reports the relative result to the user.
[1] Hardware User's Guide of the used module
SIM Presence
Setting saved
Can be aborted
MAX timeout
SELINT
Required
Auto
No
-
2
AT#JDRENH2=<mode>[,<sat2G>,<unused>,<carrNum2G>,<pRxLevT2G>,<unused>,
<unused>,<unused>[,<P_RSSI_T4G>[,<P_RSRQ_T4G>[,<unused>]]]]
The set command performs the following activities:
• enables/disables the detection of the presence of jamming in the module coverage.
• selects one of the following two reports mode or both: on dedicated GPIO, by means of
the URC, or GPIO + URC.
Parameters:
Name
Type
Default
Description
<mode>
integer
0
enable/disable jamming detection and select reporting
mode
Values:
0
:
disable jamming detection
1
:
enable jamming detection, and report its condition on a GPIO pin,
see Additional info section
2
:
enable jamming detection, and report its condition with an URC,
see Additional info section
3
:
enable jamming detection, and report its condition as <mode>=1
and <mode>=2
4
:
enable jamming detection, and report its condition with an URC
every 3 sec, see <mode>=2
5
:
enable jamming detection, and report its condition as <mode>=1
and <mode>=4
6
:
not used
<sat2G>
integer
45
is the starting absolute threshold of RSSI 2G Network.
After a frequency scan in 2G bands, if the measured
power of a carrier is greater than <sat2G> threshold,
that carrier is counted as possible jammed carrier.
Value:
0÷63
:
threshold values
<unused>
integer
N/A
unused parameter
Value:
