TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012
www.ti.com
Table 2-3. Terminal Functions (continued)
SIGNAL
TYPE
(1)
IPD/IPU
(2)
DESCRIPTION
NAME NO.
RAPIDIO SERIAL PORT
RIOCLK AF15 I RapidIO serial port source (reference) clock
RIOCLK AG15 I Negative RapidIO serial port source (reference) clock
RIOTX3 AF17 O/Z
RIOTX2 AG18
RapidIO transmit data bus bits [3:0] (differential)
RIOTX1 AG22
RIOTX0 AF23
RIOTX3 AF18 O/Z
RIOTX2 AG19
RapidIO negative transmit data bus bits [3:0] (differential)
RIOTX1 AG21
RIOTX0 AF22
RIORX3 AH18 I
RIORX2 AJ18
RapidIO receive data bus bits [3:0] (differential)
RIORX1 AJ22
RIORX0 AH22
RIORX3 AH17 I
RIORX2 AJ19
RapidIO negative receive data bus bits [3:0] (differential)
RIORX1 AJ21
RIORX0 AH23
MANAGEMENT DATA INPUT/OUTPUT (MDIO) FOR MII/RMII/GMII
UTOPIA transmit address pin 4 (UXADDR4) (I) or MDIO serial clock (MDCLK)
UXADDR4/MDCLK M5 I/O/Z IPD
for MII/RMII/GMII mode (O)
UTOPIA transmit address pin 3 (UXADDR3) (I) or MDIO serial data (MDIO) for
UXADDR3/MDIO N3 I/O/Z IPU
MII/RMII/GMII mode (I/O)
MANAGEMENT DATA INPUT/OUTPUT (MDIO) FOR RGMII
RGMDCLK B4 O/Z MDIO serial clock (RGMII mode) (RGMDCLK) (O)
RGMDIO A4 I/O/Z MDIO serial data (RGMII mode) (RGMDIO) (I/O)
ETHERNET MAC (EMAC) [MII/RMII/GMII]
If the Ethernet MAC (EMAC) and MDIO are enabled (AEA12 driven low [UTOPIA_EN = 0]), there are two additional configuration pins - the
MAC_SEL[1:0] (AEA[10:9] pins) - that select one of the four interface modes (MII, RMII, GMII, or RGMII) for the EMAC/MDIO interface. For
more detailed information on the EMAC configuration pins, see Section 3, Device Configuration.
UTOPIA receive clock (URCLK) driven by Master ATM Controller (I) or when
the UTOPIA peripheral is disabled (UTOPIA_EN [AEA12 pin] = 0), this pin is
URCLK/MRCLK H1 I
EMAC receive clock (MRCLK) for MII [default] or GMII. MACSEL[1:0]
dependent.
UTOPIA receive cell available status output signal from UTOPIA Slave (O) or
URCLAV/MCRS/ when the UTOPIA peripheral is disabled (UTOPIA_EN [AEA12 pin] = 0), this
J4 I/O/Z
RMCRSDV pin is EMAC carrier sense (MCRS) (I) for MII [default] or GMII, or EMAC carrier
sense/receive data valid (RMCRSDV) (I) for RMII. MACSEL[1:0] dependent.
UTOPIA receive Start-of-Cell signal (I) or when the UTOPIA peripheral is
URSOC/MRXER/
H4 I disabled (UTOPIA_EN [AEA12 pin] = 0), this pin is EMAC receive error
RMRXER
(MRXIR) (I) for MII [default], RMII, or GMII. MACSEL[1:0] dependent.
UTOPIA receive interface enable input signal (I). Asserted by the Master ATM
Controller to indicate to the UTOPIA Slave to sample the Receive Data Bus
(URDATA[7:0]) and URSOC signal in the next clock cycle or thereafter.
URENB/MRXDV H5 I
When the UTOPIA peripheral is disabled (UTOPIA_EN [AEA12 pin] = 0), this
pin is EMAC MII [default] or GMII receive data valid (MRXDV) (I). MACSEL[1:0]
dependent.
38 Device Overview Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
