3.4.4 Peripheral Status Registers Description
The Peripheral Status Registers (PERSTAT0 and PERSTAT1) show the status of the C6455 device
peripherals.
31 30 29 27 26 24
Reserved HPISTAT McBSP1STAT
R-0 R-0 R-0
23 21 20 18 17 16
McBSP0STAT I2CSTAT GPIOSTAT
R-0 R-0 R-0
15 14 12 11 9 8
GPIOSTAT TIMER1STAT TIMER0STAT EMACSTAT
R-0 R-0 R-0 R-0
7 6 5 3 2 0
EMACSTAT VCPSTAT TCPSTAT
R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Figure 3-6. Peripheral Status Register 0 (PERSTAT0) - 0x02AC 0014
Table 3-9. Peripheral Status Register 0 (PERSTAT0) Field Descriptions
Bit Field Value Description
31:30 Reserved Reserved.
29:27 HPISTAT HPI status
000 HPI is in the disabled state
001 HPI is in the enabled state
011 HPI is in the static powerdown state
100 HPI is in the disable in progress state
101 HPI is in the enable in progress state
Others Reserved
26:24 McBSP1STAT McBSP1 status
000 McBSP1 is in the disabled state
001 McBSP1 is in the enabled state
011 McBSP1 is in the static powerdown state
100 McBSP1 is in the disable in progress state
101 McBSP1 is in the enable in progress state
Others Reserved
23:21 McBSP0STAT McBSP0 status
000 McBSP0 is in the disabled state
001 McBSP0 is in the enabled state
011 McBSP0 is in the static powerdown state
100 McBSP0 is in the disable in progress state
101 McBSP0 is in the enable in progress state
Others Reserved
