Table 3-9. Peripheral Status Register 0 (PERSTAT0) Field Descriptions (continued)
Bit Field Value Description
20:18 I2CSTAT I2C status
000 I2C is in the disabled state
001 I2C is in the enabled state
011 I2C is in the static powerdown state
100 I2C is in the disable in progress state
101 I2C is in the enable in progress state
Others Reserved
17:15 GPIOSTAT GPIO status
000 GPIO is in the disabled state
001 GPIO is in the enabled state
011 GPIO is in the static powerdown state
100 GPIO is in the disable in progress state
101 GPIO is in the enable in progress state
Others Reserved
14:12 TIMER1STAT Timer1 status
000 Timer1 is in the disabled state
001 Timer1 is in the enabled state
011 Timer1 is in the static powerdown state
100 Timer1 is in the disable in progress state
101 Timer1 is in the enable in progress state
Others Reserved
11:9 TIMER0STAT Timer0 status
000 Timer0 is in the disabled state
001 Timer0 is in the enabled state
011 Timer0 is in the static powerdown state
100 Timer0 is in the disable in progress state
101 Timer0 is in the enable in progress state
Others Reserved
8:6 EMACSTAT EMAC/MDIO status
000 EMAC/MDIO is in the disabled state
001 EMAC/MDIO is in the enabled state
011 EMAC/MDIO is in the static powerdown state
100 EMAC/MDIO is in the disable in progress state
101 EMAC/MDIO is in the enable in progress state
Others Reserved
5:3 VCPSTAT VCP status
000 VCP is in the disabled state
001 VCP is in the enabled state
011 VCP is in the static powerdown state
100 VCP is in the disable in progress state
101 VCP is in the enable in progress state
Others Reserved
Copyright © 2005–2012, Texas Instruments Incorporated Device Configuration 67
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455

Texas Instruments TMS320C6455 Specifications

General

Clock Speed	1.0 GHz
Core Count	1
On-Chip RAM	Yes
Data Width	32-bit
Data Bus Width	64-bit
Operating Voltage	1.2 V
I/O Voltage	3.3 V
Instruction Set	TMS320C64x+
Memory	DDR2
Package Type	BGA
External Memory Interface	EMIF
Interfaces	I2C, SPI

Summary

1 Features

2 Device Overview

2.1 Device Characteristics

2.2 CPU (DSP Core) Description

Details the C64x+ CPU core, functional units, register files, and data paths.

2.3 Memory Map Summary

2.4 Boot Sequence

Explains the process of initializing the DSP's memory and registers at reset.

3 Device Configuration

3.1 Device Configuration at Device Reset

Details configuration pins (AEA, ABA, PCI_EN) for boot mode, clock source, and endianness.

3.2 Peripheral Configuration at Device Reset

3.4 Device State Control Registers

3.5 Device Status Register Description

5 C64x+ Megamodule

5.1 Memory Architecture

Describes the L2, L1P, and L1D memory configurations and sizes.

5.2 Memory Protection

5.3 Bandwidth Management

6 Device Operating Conditions

6.1 Absolute Maximum Ratings Over Operating Case Temperature Range (Unless Otherwise Noted)

Specifies stress ratings for voltage, temperature, and other conditions beyond which damage may occur.

6.2 Recommended Operating Conditions

Lists recommended operating ranges for supply voltages, input/output, and temperatures.

6.3 Electrical Characteristics Over Recommended Ranges of Supply Voltage and Operating Case Temperature (Unless Otherwise Noted)

Details electrical characteristics under specified operating conditions.

7 C64x+ Peripheral Information and Electrical Specifications

7.1 Parameter Information

7.3 Power Supplies

Covers power supply sequencing, decoupling, and power-down operation.

7.4 Enhanced Direct Memory Access (EDMA3) Controller

Details EDMA3 features like transfer dimensions, PaRAM entries, and DMA channels.

7.5 Interrupts

7.6 Reset Controller

Describes different reset types (POR, Warm, Max, System, CPU) and their effects.

7.7 PLL1 and PLL1 Controller

Details PLL1 controller operation, clocks, and registers for frequency synthesis.

7.8 PLL2 and PLL2 Controller

Describes PLL2 controller operation, clocks, and registers for EMAC and DDR2 memory.

7.9 DDR2 Memory Controller

Explains DDR2 interface, device-specific information, and memory topologies.

7.10 External Memory Interface A (EMIFA)

Covers EMIFA interface capabilities for various external devices and timing.

7.11 I2C Peripheral

Describes the I2C module, its features, and device-specific information.

7.12 Host-Port Interface (HPI) Peripheral

7.13 Multichannel Buffered Serial Port (McBSP)

7.14 Ethernet MAC (EMAC)

Describes EMAC module, interface modes (MII, RMII, GMII, RGMII), and control modules.

7.15 Timers

7.16 Enhanced Viterbi-Decoder Coprocessor (VCP2)

7.17 Enhanced Turbo Decoder Coprocessor (TCP2)

7.18 Peripheral Component Interconnect (PCI)

7.20 Serial RapidIO (SRIO) Port

7.22 Emulation Features and Capability
