Thales FMGS - Enter Climb Wind

FLIGHT PHASES
PREFLIGHT 13
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
 Enter Climb Wind
Either enter forecast wind and
associated altitude/FL and proceed
as below; or proceed to Enter
History Wind on next page.
WIND [5R] .................... Press
This provides access to the CLIMB
WIND page.
TRU WIND/ALT[1L]........Enter
Enter forecast winds & associated
altitudes or FLs on climb.
Up to five different winds can be
inserted in the CLIMB WIND page.
Ex: 180/20/100 (as predicted in
the flight plan: 180°/20 kt at
FL100).
Repeat the operation to insert the
other predicted wind.
Ex: 270°/30/FL200,
350°/40/FL300, 300°/40/FL360.
The wind entered for top of climb
will be used for predictions during
cruise unless specific cruise winds
are entered (see below).
All wind directions are True.
If needed to correct after insertion,
re-enter with the following data
format:
XXX/XX (xxx°/xx KT), or /XXX (FL)
By pressing the UPDATE INSERT
amber prompt, the MCDU display
switches to the F-PLN page.
The optional WIND REQUEST field
and amber prompt are described in
Part III: Multiphase – Data Link.
INIT {}
CO RTE FROM/TO
TLSLHR01 LFBO/EGLL
ALTN/CO RTE
EHAM/LHRAMS01
FLT NBR
THV001
LAT
$£ LONG
4338.1N 00122.1E
COST INDEX
30 WIND>
CRZ FL/TEMP TROPO
FL360 /-50° 35000
CLIMB WIND
TRU WIND/ALT HISTORY
[ ]°/[ ]/[ ] WIND>
WIND
REQUEST*
NEXT
PHASE>
<RETURN
180/20/100
CLIMB WIND
TRU WIND/ALT HISTORY
180°/020/FL100 WIND>
[ ]°/[ ]/[ ]
WIND
REQUEST*
NEXT
PHASE>
UPDATE UPDATE
{CANCEL INSERT*
CLIMB WIND
TRU WIND/ALT HISTORY
180°/020/FL100 WIND>
270°/030/FL200
WIND
350°/040/FL300 REQUEST*
300°/040/FL360
NEXT
[ ]°/[ ]/[ ] PHASE>
UPDATE UPDATE
{CANCEL INSERT*
FROM THV001 {}
FIST5A TIME SPD/ALT
LFBO14R ---- ---/ 490
H144° BRG144° 1
900 ---- ---/ -----
C144° TRK144° 4
D144H} ---- ---/ -----
C356° 2
