VERTICAL F-PLN management 17
 To enter or modify ALT CSTR at a WPT
From F-PLN page, access VERT REV
page by right LSK, at revise point.
ALT CSTR [3R]................Enter
− For AT ALT CSTR, enter altitude or
FL.
Ex: cross TOU at FL 80, enter 80
− For AT OR ABOVE CSTR, enter
altitude or FL preceded or followed by
"+" sign.
− For AT OR BELOW CSTR, enter
altitude or FL preceded or followed by
"-" sign.
An altitude entered in FT above TRANS
ALT is automatically converted to FL and
vice versa below TRANS ALT.
TMPY F-PLN is displayed.
FMGC computes profile to comply
with CSTR as closely as possible,
within performance limits of A/C;
predicted altitude/FL at revise point
are displayed.
VERT REV AT TOU
EFOB=7.2 EXTRA=1.3
CLB SPD LIM UTC CSTR
250/FL100 [ ]
SPD CSTR ALT CSTR
[ ] [ ]
ACCESS
<WIND DATA STEP ALTS>
<RETURN
80
FROM THV001 {}
FIST5A UTC SPD/ALT
LFBO14R 0000 141/ 490
H144° BRG144° 1
900 0000 153/ 900
C144° TRK144° 4
D144H} 0002 " / *3130
C356° 8
TOU 0005 250/ FL85
(SPD) 3NM
(LIM) 0005 *250/FL100
DEST UTC DIST EFOB
EGLL27R 0125 532 4.
£$
VERT REV AT TOU
EFOB=7.1 EXTRA=1.1
CLB SPD LIM UTC CSTR
250/FL100 [ ]
SPD CSTR ALT CSTR
[ ] FL080
STEP ALTS>
TMPY
<F-PLN
FROM THV001 {}
FIST5A UTC SPD/ALT
LFBO14R 0000 141/ 490
H144° BRG144° 1
900 0000 153/ 900
C144° TRK144° 4
D144H} 0002 " / *3130
C356° 8
TOU 0005 250/ *FL80
(SPD) 3NM
(LIM) 0005 *250/FL100
DEST UTC DIST EFOB
EGLL27R 0125 532 4.3
£$
FROM TMPY THV001 {}
FIST5A UTC SPD/ALT
LFBO14R 0000 141/ 490
H144° BRG144° 1
900 0000 100/ 900
C144° TRK144° 4
D144H} 0003 " / *3130
C356° 8
TOU 0007 250/ FL80
(SPD) 3NM
(LIM) 0008 *250/FL100
TMPY TMPY
{ERASE INSERT*
£$
 If ALT CSTR predicted as
matched:
TMPY F-PLN shows predicted ALT at
revise point preceded by * symbol
(magenta).
 If ALT CSTR predicted as
missed:
TMPY F-PLN shows predicted ALT at
revise point preceded by * symbol
(amber).
TMPY INSERT [6R] ........ Press
