Thales FMGS - FCU Selection for Take-Off; Take-Off with Preset HDG

FLIGHT PHASES
PREFLIGHT 39
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
 FCU selection for take-off
The normal FCU selection with associated FMA and PFD display is:
Ex: DEP LFBO for FISTO5A altitude clearance 7000ft.
If ACC ALT is above the FCU selected ALT, CLB is replaced by ALT blue
or, ALT magenta if a more restrictive constraint exists.
 Take-off with preset HDG:
FCU............................ Set HDG
Rotate FCU knob to preset the HDG value on the FCU.
Dot disappears.
Do not pull HDG knob.
PFD/FMA
− NAV mode is disarmed,
− Preselected HDG is shown
(blue) on heading scale.
ND
The F-PLN route becomes
dashed green, and blue HDG
index is displayed.
See Part II: Ch 3 - Take-off.
To cancel preset HDG and re-
arm NAV, push HDG knob.
=fQQ
=
J
=
J
=
J
=
J
=
J
=
J
=
J
=
J
=
J
=
J
=
J
=
MTMMM
=
NAV 1FD2 CLB
1FD2 CLB
