Thales FMGS - DIVERSION to ALTN Airport; ENABLE ALTN Function

FLIGHT PHASES
10 GO-AROUND
FROM THV001 {}
UTC SPD/ALT
FI27R ---- / -----
C273° BRG274° 1-3.0°
EGLL27R&---- ---/ -----
C273° TRK273° 3
1580 ---- ---/ -----
C320° 3
3000 ---- ---/ -----
---F-PLN DISCONTINUITY--
DEST UTC DIST EFOB
EGLL27R ---- 26 -----
£$
THV001 {}
UTC SPD/ALT
---F-PLN DISCONTINUITY--
CI27R ---- ---/ *2500
C273° TRK273° 3-3.0°
FI27R ---- ---/ 2500
C273° 4-3.0°
EGLL27R&---- ---/ 130
C273° 3NM
1580 ---- ---/ -----
DEST UTC DIST EFOB
EGLL27R ---- 26 -- ---
£$
THV001 {}
C273° UTC SPD/ALT
1580 ---- ---/ -----
C320° 3
3000 ---- ---/ -----
-------END OF F-PLN-----
EGLL ---- ---/ 80
21NM
BPK ---- ---/ -----
DEST UTC DIST EFOB
EGLL27R ---- 26 -----
£$
THV001 {}
H139° UTC SPD/ALT
INTCPT ---- ---/ -----
C184° 0
EH621 ---- ---/ *2000
C184° TRK185° 2-3.0°
EH622 ---- ---/ 2000
C184° 4-3.0°
EHAM18R ---- ---/ 40
EHA184 1NM
390 } ---- ---/ -----
DEST UTC DIST EFOB
EGLL27R ---- 26 -----
£$
THV001 {}
C184° UTC SPD/ALT
EHAM18R ---- ---/ 40
EHA184 1
390 } ---- ---/ -----
C325° 1
INTCP ---- ---/ -----
C184° 5
EH624 ---- ---/ 2000
---END OF ALTN F-PLN----
DEST UTC DIST EFOB
EGLL27R ---- 26 -----
£$
1
2
3
8.4. DIVERSION to ALTN Airport

ENABLE ALTN function
This function may be used when an ALTN
airport is entered.
In the example ALTN to EHAM has been
prepared with the following route:
EGLL 27R BPK6F BPK DCT CLN UL620
REDFA EHAM ILS 18R
The content of F-PLN page is:
1 GA procedure at EGLL27R
--F-PLN DISCONTINUITY--
2 New ILS EGLL27R
New GA procedure at EGLL27R
---END OF F-PLN---
3 EGLL
Alternate route to EHAM
ILS EHAM18R
GA procedure EHAM 18R
--END OF ALTN F-PLN--
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
