 NEW DEST
This function is used to change the
DEST airport either after a go-around
if a diversion is intended or at any
time for an en-route diversion.
LAT REV must be selected at the
WPT from which it is intended to
divert.
An example of diversion after a go-
around is described in Part II: Go-
around Ch 8.4 (Diversion not
prepared).
In the following example it is
intended to divert to LFBD at FOUCO.
LAT REV at revise point....Press
NEW DEST [4R]..............Enter
Ex: LFBD
TMPY F-PLN is displayed.
All WPTs after the revise point
(FOUCO) are deleted.
Route to the new DEST must be
entered.
FROM THV001 {}
UTC SPD/ALT
FISTO 1514 / FL287
UN874 BRG340° 55
FOUCO 1525 .79/ FL340
UN874 48
ADABI 1532 " / "
UN874 30
BOKNO 1536 " / "
UN874 27NM
DEVRO 1540 " / "
DEST UTC DIST EFOB
EGLL27R 1625 443 4.3
£$
LAT REV FROM FOUCO
45°45.3N/000°28.8E
NEXT WPT
<HOLD [ ]
ENABLE NEW DEST
{ALTN [ ]
AIRWAYS>
<RETURN
LFBD
FROM TMPY THV001 {}
UTC SPD/ALT
FISTO 1514 / FL287
UN874 BRG340° 49
(T/D) 1531 .79/ FL340
UN874 TRK339° 35
FOUCO 1536 290/ FL232
---F-PLN DISCONTINUITY--
(SPD)
(LIM) 1552 *250/ FL100
TMPY TMPY
{ERASE INSERT*
£$
FROM TMPY THV001 {}
UTC SPD/ALT
---F-PLN DISCOBTINUITY--
(SPD)
(LIM) 1552 *250/ FL100
36
(DECEL) 1600 250/ 210
0
LFBD 1600 137/ 210
------END OF F-PLN------
TMPY TMPY
{ERASE INSERT*
£$
