MULTIPHASE
10 DATA LINK
 F-PLN DATA and PERF DATA UPLINK messages
Following an INIT REQUEST ground station may uplink two types of
messages: F-PLN DATA and PERF DATA.
The pilot INIT REQUEST is general and does not specify F-PLN DATA or
PERF DATA REQUEST. Depending on ground station capability the
uplinked response contains F-PLN DATA and/or PERF DATA.
Ground station can send messages to A/C without pilot REQUEST.
Data are uplinked to ACTIVE F-PLN or SEC F-PLN depending on status
specified in the message.

Before Engine Start
Screens shown are examples
F-PLN DATA are uplinked and inserted
automatically:
INIT {}
CO RTE FROM/TO
TLSLHR01 LFBO/EGLL
ALTN/CO RTE
EHAM
FLT NBR
________
LAT LONG
----.-- -----.--
COST INDEX
--- WIND>
CRZ FL/TEMP TROPO
----- /---° 36090
AOC ACT F
-
PLN UPLINK
− In ACTIVE F-PLN or SEC F-PLN
depending on status specified in the
message.
− In SEC F-PLN if an ACTIVE F-PLN
already exists.
THV001
LAT LONG
4338.1N 00122.1E
COST INDEX
30 WIND>
CRZ FL/TEMP TROPO
FL360/-50° 36090
AOC SEC F
-
PLN UPLINK
INIT {}
CO RTE FROM/TO
TLSLHR01 LFBO/EGLL
ALTN/CO RTE
EHAM
FLT NBR
AOC ACT F-PLN UPLINK or AOC SEC F-
PLN UPLINK scratchpad messages (white)
advise pilot that data have been uplinked
and inserted in ACTIVE F-PLN or SEC F-
PLN.
PERF DATA are uplinked and inserted
automatically:
− In ACTIVE F-PLN if already exists,
− In SEC F-PLN if no ACTIVE F-PLN
exists.
INIT {}
CO RTE FROM/TO
TLSLHR01 LFBO/EGLL
ALTN/CO RTE
EHAM
FLT NBR
THV001
LAT LONG
4338.1N 00122.1E
COST INDEX
30 WIND>
CRZ FL/TEMP TROPO
FL360/-50° 36090
PERF DATA UPLINK
PERF DATA UPLINK scratchpad message
(white) advises pilot that data have been
uplinked and inserted).
This message is rejected without any
scratchpad message if no ACTIVE or SEC
F-PLN exists.
J43126AA 00
