FLIGHT PHASES
CRUISE 19
 Enter/Revise alternate route
If needed.
 Check F-PLN
Arrival should be checked for adherence to approach charts.
Compare arrival routing and profile as shown on F-PLN page and ND
(PLAN mode), scrolling as necessary.
Clear any discontinuities (except in case of MANUAL LEG)
Check or enter needed constraints.
Refer also to:
− Part II: Preflight – 2.1 Check F-PLN,
− Part III: Ch 3 & 4 – LAT & VERT functions.
Caution
After insertion from NAV data base arrival and approach procedure
should not be modified.
Refer to SOPs for acceptable modification.
Consider raw data if divergence from official procedures.
THV001 {}
C335 UTC SPD/ALT
BIG07
U
2045 137/ *2500
C273° 7
C127R 2048 " / *2500
C273° TRK273° 3-3.0°
F127R 2050 " / 1400
C273° 4-3.0°
EGLL27R
U
2052 137/ 130
C273° 3NM
1580 ---- ---/ -----
DEST UTC DIST EFOB
EGLL27R 2052 212 4.1
£$
