 DIR TO RADIAL IN / RADIAL OUT functions
 DIR TO RADIAL IN
This function is used primarily during initial or intermediate approach.
The DIR TO RADIAL IN function at arrival is described in Part II:
Descent – 6.5 F-PLN sequencing.
It may be used during other in-flight phases in the same way.
In the example below it is intended to proceed to AMB on radial 185.
− DIR TO page is accessed
− AMB is entered in [1L]
− 185 is entered in [4R]
− On ND TMPY F-PLN track is displayed in yellow.
DIR TO
WAYPOINT UTC DIST
AMB 1540 121
F-PLN WPTS
{BOKNO DIRECT TO }
WITH
{DEVRO ABEAM PTS }
RADIAL IN
{VANAD 185°
RADIAL OUT
{VADOM [ ]°
DIR TO DIR TO
{ERASE INSERT*
£$
