Thales FMGS - DUPLICATE NAMES Page

MULTI PHASE
18 NAVIGATION management & monitoring
 DUPLICATE NAMES page
This page cannot be accessed directly.
It is automatically displayed when an ident is entered if NAVdb or Pilot
stored data contain other item(s) having same ident.
This applies to the following pages:
INIT A : [1R], [2L]
F.PLN A : any left LSK except 6L
F.PLN B : any left LSK except 6L
ALTN : other ALTN field
LAT REV : [3R] or [4R]
AIRWAY : any right LSK except 6R
SEC INIT A : [1R], [2L]
SEC F.PLN A : any left LSK except 6L
SEC F.PLN B : any left LSK except 6L
PROG : [3L], [4R]
NAVAID : [1L]
WAYPOINT : [1L]
RUNWAY : [1L]
ROUTE : [1R]
DIR TO : [1L]
RAD NAV : [1L], [3L], [5L], [1R], [3R], [5R]
SEL NAVAID : any right LSK
NEW WAYPOINT : [3L], [4L]
PREDICTIVE GPS : [3L]
In the example it is attempted to
revise ACTIVE F-PLN after ADABI to
proceed to AMB.
FROM THV001 {}
UTC SPD/ALT
T-P 1522 / FL358
BRG357° 68
ADABI 1532 .79/ FL360
TRK016° 30
BOKNO 1536 " / "
UN874 TRK007° 27
DEVRO 1540 " / "
UN874 22NM
VANAD 1543 " / "
DEST UTC DIST EFOB
EGLL27R 1625 532 4.3
AMB £$
DUPLICATE NAMES
38NM LAT/LONG FREQ
*AMB 45N/000E
120NM
*AMB 47N/001E 341.0
121NM
*AMB 47N/001E 113.70
5001NM
*AMB 01S/078W 360.0
6113NM
*AMB 33S/070W 116.10
<RETURN
£
− AMB [3L] is entered,
− DUPLICATE NAMES Page is
automatically displayed because
AMB is not a unique ident found if
NAV data references.
DUPLICATE NAMES page is described
below.
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
