MCDU NAMING and DATA FORMAT 9
Abeam reference point (AB)
If the flight crew inserts an
abeam reference point into the
F-PLN via the DIR TO function,
the FM abbreviates this to
ABXXXXX, where AB is static
and XXXXX are the first five
characters of the reference, or
parent, waypoint. If fewer than
5 characters exist, then only t
existing characters are used
he
.
BXXXXX becomes the identifier
be
A
of the waypoint and may
used as for any other waypoint
identifier. However, this
waypoint does not become one
of the twenty pilot defined waypoints.
DIR TO
WAYPOINT UTC DIST
ADABI 1224 75
F-PLN WPTS
{ADABI DIRECT TO }
WITH
{BOKNO ABEAM PTS
RADIAL IN
{DEVRO 184° }
RADIAL OUT
{VANAD [ ]°
DIR TO DIR TO
{ER INSERT*ASE
$£
THV001 {}
UTC SPD/ALT
ABFOUCO 1217 .79/ FL360
48
ADABI 1224 " / "
UN874 TRK016° 30
BOKNO 1228 " / "
UN874 27
DEVRO 1232 " / "
UN874 22NM
VANAD 1234 " / "
DEST UTC DIST EFOB
EGLL27R 1319 415 3.8
£$
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
