Thales FMGS - ALTERNATE Function; ALTERNATES Page; Without ALTN in Navdb

62
MULTIPHASE
LATERAL F-PLN management
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
3.6. ALTERNATE function
 ALTERNATES page
ALTERNATES page enables to review
and/or revise an ALTN during any
flight phase.
It is accessed by ALTN prompt via LAT
REV at DEST from F-PLN page A or B.
LAT REV at DEST [6L].....Press
ALTN [3L].......................Press
The ALTERNATES page for the current
destination is displayed.
Title is yellow if a TMPY F-PLN already
exists.
 Without ALTN in NAVdb
If NAVdb does not contain specific
ALTN(s) associated with the selected
DEST airport:
− [1L] shows selected ALTN (green if
associated with ACTIVE F-PLN,
yellow if associated TMPY F-PLN);
[1R] shows code of ALTN CO RTE if
any.
− [Line 3] shows selected ALTN, with
TRK (great circle), EXTRA fuel (zero
wind) and DIST for the entered
ALTN F-PLN route.
− [line 4] shows NO ALTN with EXTRA
fuel.
Example shows EHAM (green) entered as ALTN for EGLL.
FROM THV001 {}
UTC SPD/ALT
T-P 1449 / FL360
BRG010° 6
(T/D) 1635 .79/ FL360
TRK010° 17
DIMAL 1637 " / FL308
7
ALESO 1638 293/ FL286
BIG3B 42NM
TIGER 1644 " /*FL154
DEST UTC DIST EFOB
EGLL27R 1657 115 3.8
$£
LAT REV FROM EGLL27R
51°20.7N/000°26.0W
ARRIVAL>
NEXT WPT
<ALTN [ ]
ENABLE
{ALTN
<RETURN
ALTERNATES FOR EGLL
ALTN CO RTE
EHAM
TRK EXTRA DIST
OTHER ALTN
EHAM 075° 1.0 199
EXTRA
{NO ALTN 3.1
<RETURN
