Thales FMGS - MCDU Display; Pilots Routes; Sec F-Pln

4
FLIGHT PHASES
DONE
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
 MCDU display:
After landing when FMGC switches to
DONE phase:
− If displayed, PROG APPR page
switches to PROG DONE page,
− All other pages switch to A/C
STATUS page.
Pictures shows MCDU pages if
associated key is pressed:
− F-PLN: F-PLN page shows all
elements erased, first line shows
PPOS, ND is blank,
− FUEL PRED
INIT B page remains not available
until engines are shut down,
− RAD NAV,
− IRS MONITOR page displays IRS
drift.
This page remains until IRS are
either switched off or re-aligned or
next TAKE OFF phase.
If INIT is pressed, FMGC switches to
PREFLIGHT phase (See 9.4 in this
chapter).
 SEC F-PLN:
− If created via SEC INIT page, it is
stored, and may be ACTIVATED for
the next flight,
− If created by COPY ACTIVE, it is
erased. This applies whether or not
the SECONDARY F-PLN is
sequenced.
 PILOTS ROUTES:
Pilot stored routes are either deleted
or retained, depending on option
selected in AMI file.
FROM {}
TIME SPD/ALT
PPOS ---- / -----
---F-PLN DISCONTINUITY--
------END OF F-PLN------
------NO ALTN F-PLN-----
DEST TIME DIST EFOB
------- ---- ---- -----
FUEL PRED
AT TIME EFOB
NONE ---- ---.-
NONE ---- ---.-
GW /CG FOB
__._ /__._ 3.97/FF+FQ
RTE RSV/% CRZTEMP/TROPO
---.-/ 5.0 ----°/36090
FINAL/TIME
---.-/0030
EXTRA/TIME
---.-/----
RADIO NAV
VOR1/FREQ FREQ/VOR2
&LON/113.60 117.50/BPK
CRS CRS
[ ] [ ]
ILS /FREQ CHAN/ MLS
IRR/110.30 [ ]/[ ]
CRS SLOPE CRS
F273 -.- [ ]
ADF1/FREQ FREQ/ADF2
[ ]/[ .] 277.0/CHT
ADF2 BFO
DATA INDEX 1/2 {}
POSITION
<MONITOR
IRS
<MONITOR
GPS
<MONITOR
<A/C STATUS
PRINT
FUNCTION>
AOC
FUNCTION>
IRS MONITOR
DRIFT AT EGLL27R
<IRS1
NAV DRIFT 0.5NM/H
<IRS2
NAV DRIFT 1.5NM/H
<IRS3
NAV DRIFT 2.5NM/H
