Thales FMGS - To Enter or Modify CLB or des SPD LIM

MULTIPHASE
4 VERTICAL F-PLN management
 To enter or modify CLB or DES SPD LIM
From F-PLN page access VERT REV page by right LSK, at any WPT
before T/D for CLB, or after T/D for DES.
VERT REV at WPT ..........Press
Select vertical revision at the
desired WPT. Ex TOU
VERT REV page is displayed.
CLB (or DES) SPD LIM [2L] .....
......................................Enter
For an initial entry, enter SPD/ALT
or SPD/FL, ex: 210/5000 or
210/50.
If SPD LIM value already exists,
either or both may be entered,
ex: 210 or /5000.
In the example: 280/150
A TMPY F-PLN containing the
entered or modified SPD LIM is
created, and TMPY F-PLN page is
displayed.
If selected VERT REV page is
shown yellow.
TMPY INSERT [6R].........Press
(SPD)(LIM) values are entered in
ACTIVE F-PLN.
VERT REV AT SPDLIM
CLB SPD LIM
280/FL150
TMPY
{F-PLN
FROM TMPY THV001 {}
UTC SPD/ALT
D144H} 0300 / 3810
C356° BRG325° 8
VERT REV AT TOU
EFOB=7.1 EXTRA=1.3
CLB SPD LIM UTC CSTR
250/FL100 [ ]
SPD CSTR ALT CSTR
[ ] [ ]
ACCESS
<WIND DATA STEP ALTS>
<RETURN
280/150
FROM THV001 {}
UTC SPD/ALT
D144H} 0300 / 3810
(SPD) BRG339° 10
(LIM) 1130 *250/ FL100
C356° TRK325° 0
TOU 1130 306/ FL123
37
(T/C) 1136 .79/ FL360
FIST5A 10NM
FISTO 1138 " / "
DEST UTC DIST EFOB
EGLL27R 1249 529 4.3
£$
FROM THV001 {}
UTC SPD/ALT
D144H} 0300 / 3810
C356° BRG339° 10
TOU 1132 280/ FL123
(SPD) TRK357° 4
(LIM) 1133 *280/ FL150
33
(T/C) 1138 .79/ FL360
FIST5A 10NM
FISTO 1140 " / "
DEST UTC DIST EFOB
EGLL27R 1251 529 4.3
£$
TOU 1131 280/ FL123
(SPD) TRK357° 4
(LIM) 1132 *280/ FL150
33
(T/C) 1138 .79/ FL360
FIST5A 10NM
FISTO 1139 " / "
TMPY TMPY
{ERASE INSERT*
$£
J43126AA 00
