Thales FMGS - Airways

10
MULTIPHASE
LATERAL F-PLN management
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
 AIRWAYS
An example of use AIRWAYS function
is described in Part II: Preflight Ch
2.2.
The AIRWAYS function may be used
to enter or revise F-PLN containing
AWYs segments, saving time and
reducing risk of error.
AIRWAYS is accessed from any WPTs
except PPOS, DEST, Pseudo WPTs
and F-PLN markers (e.g. F-PLN
DISCONTINUITY).
General rules:
− Entered AWY in VIA field [1L] must
match where the revision is
intended,
− Entered WPT in the TO field [1R]
must belong to the entered AWY.
Otherwise entry is not accepted and
"AWY/WPT MISMATCH" s-pad msg
(white) is triggered.
ND should be used with appropriate
mode/range to check entered
revisions.
FROM THV001 {}
UTC SPD/ALT
FISTO 1514 / FL287
BRG339° 26
(T/C) 1514 .79/ FL360
UN874 TRK339° 50
FOUCO 1525 " / "
UN874 48
ADABI 1532 " / "
UN874 30NM
BOKNO 1536 " / "
DEST UTC DIST EFOB
EGLL27R 1625 464 4.3
£$
LAT REV FROM FOUCO
45°45.3N/000°28.8E
NEXT WPT
<HOLD [ ]
ENABLE NEW DEST
{ALTN [ ]
AIRWAYS>
<RETURN
UT158
AIRWAYS FROM FOUCO
VIA
[ ]
<RETURN
AWY/WPT MISMATCH
AMB
AIRWAYS FROM FOUCO
VIA TO
UT209 [ ]
<RETURN
AWY/WPT MISMATCH
