FMS GENERAL DESCRIPTION
MCDU 15
Color code
There are six colors used for data display: white, green, blue (cyan),
yellow, amber and magenta.
DATA MCDU COLOR
Title, comments,
< , > , ↑ ↓ ← →
dashes,
minor messages,
TO waypoint
Destination
White
Modifiable data,
Selectable data,
Brackets,
Tuned navaid
Cyan
Non modifiable data,
active data
Green
Mandatory data (boxes),
Pilot action required,
Important messages,
Missed constraints
Amber
Constraints,
Max altitude
Magenta
ACTIVE F-PLN,
Offset (OFST in the title of F-PLN),
Active HDG SEL or active TRK SEL
Green waypoints, white legs
TMPY F-PLN Yellow waypoints, white legs
SEC F-PLN White waypoints, white legs
Missed approach,
Alternate
Cyan waypoints, white legs
*, and , associated with a prompt have the color of this prompt.
Slash (/), when used to separate data fields, are the same color and
font as of the data to the right of the /, whether the field contains
alphanumeric characters, dashes, boxes.
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
