FOREWORD
STRUCTURE OF GUIDE 5
 Text format

Figures
Tables, illustration, and drawings are not identified. They always
illustrate adjacent text.

Cautions
When it has been considered necessary to include a caution, for
example to advise of the consequences of an incorrect action, this is
identified by a Caution indication and the relevant text is boxed.
Example:
Caution
Data entered in the scratchpad should be carefully checked before
pressing the relevant Line Select Key.

Pilot's actions
All of the pilot's actions in this guide are presented as the action
sequence consisting of a control or display element and an action verb.
These actions are written using bold font.
The possible pilot's actions are:
ACTION Description and example
Enter means keying in information in MCDU scratchpad then
pressing the specified LSK to insert this entry into the
required data field.
Ex:
COST INDEX [5L] ..................Enter
This Action allows to enter the cost index written in the
scratchpad by pressing the LSK 5L.
Press means pressing specified MCDU key.
Ex:
INIT key .............................. Press
Check means verifying a value displayed on the MCDU, PFD,
ND or ECAM.
Ex:
GPS PRIMARY ......................Check
Scroll means using the MCDU slew key to adjust a value.
Ex: Vertical slew keys Scroll
Select means choosing the appropriate value or option.
Ex:
FCU SPEED ...................Select/Pull
