Thales FMGS - Diversion Not Prepared; Using SEC F-PLN

FLIGHT PHASES
GO-AROUND 13
 Using SEC F-PLN
In this example an alternate route has
been entered in SEC for EGSS (London
Stansted) via CHT and LOREL to EGSS
RWY 23
Use ND to review, sequence or modify
according to ATC clearance.
When SEC F-PLN is activated, FMGC
switches from GO AROUND to CLIMB
phase.
Refer to Part III: Multiphase - SEC F-
PLN
FROM SEC {}
UTC SPD/ALT
EGLL ---- ---/ 80
---F-PLN DISCONTINUITY--
CHT ---- ---/ -----
29
LOREL& ---- ---/ FL60
LOREL 4NM
BKY ---- ---/ -----
DEST UTC DIST EFOB
EGSS23 ---- 66 -----
£$
FROM TMPY THV001 {}
UTC SPD/ALT
1580 ---- / -----
C320° BRG320° 3
3000 ---- ---/ -----
TRK017° 7
CHT ---- ---/ -----
---F-PLN DISCONTINUITY--
EGCC ---- ---/ 310
TMPY TMPY
{ERASE INSERT*
£$
LAT REV FROM CHT
51°37.4N/000°31.1W
NEXT WPT
<HOLD [ ]
ENABLE NEW DEST
{ALTN [ ]
AIRWAYS>
<RETURN
EGCC
FROM THV001 {}
UTC SPD/ALT
1580 ---- / -----
C320° BRG303° 3
3000 ---- ---/ -----
TRK017° 7
CHT ---- ---/ -----
---F-PLN DISCONTINUITY--
CI27R ---- ---/ *2500
DEST UTC DIST EFOB
EGLL27R ---- 31 -----
£$

Diversion not prepared
In this case the diversion should be
initiated by entering the ALTN as a
NEW DEST, via the LAT REV page.
LAT REV......................... Press
NEW DES is displayed in [4R]
The NEW DEST function is not
available on LAT REV page accessed
from a “floating WPT”, i.e. a WPT
referenced to an altitude or Heading
NEW DEST [4R] ..............Enter
Enter ICAO code of desired ALTN
airport.
Ex: EGCC (Manchester)
A TMPY F-PLN is created with this
new DEST following a F-PLN
DISCONTINUITY.
Enter WPT, revise as desired.
