Thales FMGS - Data Labels

FMS GENERAL DESCRIPTION
16 MCDU
 Data Labels
Page prompts – indicate that named page may be accessed from the
page currently displayed by pressing the adjacent Line Select Key.
Data entry prompts – Different prompts are displayed in a data line
depending on the type or status of data of that line.
Blue brackets ([]) indicate that the data entry in that line is optional.
Amber boxes ( ) indicate that data entry is mandatory.
Pseudo-waypoints – A pseudo-waypoint is a waypoint generated by
the FMS and inserted in the flight plan to indicate a vertical navigation
event. Pseudo-waypoints are speed limit (SPD LIM), top of climb (T/C),
top of descent (T/D), top of step climb (S/C), top of step descent
(S/D), deceleration point (DECEL).
Flight plan markers – Markers are
displayed on the F-PLN, TMPY F-PLN
and SEC F-PLN pages to mark either:
TMPY AEC001 {}
UT210 UTC SPD/ALT
PERIG 1653 .80/ FL350
UY156 43
FOUCO 1659 " / "
---F-PLN DISCONTINUITY--
DIBAG 1700 .80/ "
UT210 45NM
TUDRA 1706 " / "
TMPY TMPY
{ERASE INSERT*
£$
− F-PLN DISCONTINUITY
(flight plan discontinuity),
− A TOO STEEP PATH,
− END OF F-PLN
(End of the flight plan),
− NO ALTN F-PLN
(No alternate flight plan).
THV001 {}
C320° UTC SPD/ALT
3000 ---- ---/ -----
------END OF F-PLN------
------NO ALTN F-PLN-----
T-P 1930 / FL120
BRG000° 37
FISTO 2256 .79/ FL314
DEST UTC DIST EFOB
EGLL27R 0003 509 4.5
£$
J43126AA 00
