Thales FMGS - With ALTN in Navdb

MULTIPHASE
LATERAL F-PLN management 65
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
 With ALTN in NAVdb
If NAVdb includes ALTN(s) for the DEST
airport (Operator option) the ALTERNATES
page shows:
− Selected ALTN [1L] and associated CO
RTE [1R] (if provided),
− List of up to 6 ALTNs linked to DEST,
− Brackets for OTHER ALTN selection,
− NO ALTN.
(scroll up if necessary to review)
For each ALTN:
− Associated CO RTE is displayed in label
line (if provided),
− Direct TRK, EXTRA fuel and ALTN
DISTANCE (as defined in the NAVdb).
If NAVdb specifies a "Preferred" ALTN in
the list:
− It is always displayed in [line 2] except
when scrolled,
− It is automatically selected when
FROM/TO field [1R] or CO RTE [1L] is
filled on INIT page A.
In the example:
− EGKK is "Preferred" alternate for EGLL and is defaulted as selected
ALTN,
− EGSS, EGCC (with CO RTE LHRMAN1), EHAM (with CO RTE
LHRAMS1), EBBR, EGPK are also listed.
Color logic is same as Departure & Arrival pages:
− Active – green,
− Selected (TMPY) – yellow,
− Available (not selected) – blue.
ALTERNATES FOR EGLL
ALTN CO RTE
EGKK
TRK EXTRA DIST
EGKK 152° 2.4 50
{EGSS 046° 2.1 80
LHRMAN1 EXTRA
{EGCC 329° 1.2 130
LHRAMS1
{EHAM 075° 1.0 199
<RETURN
£
ALTERNATES FOR EGLL
ALTN CO RTE
EGKK
TRK EXTRA DIST
{EBBR 100° 0.5 189
{EGPK 328° -0.5 283
OTHER ALTN
[ ]
EXTRA
{NO ALTN 3.8
<RETURN
