20 VERTICAL F-PLN management
 ALT WINDOW CSTRs
(not selectable by pilot)
F-PLN page A shows predicted
altitude/FL at associated WPT, with *
symbol magenta or amber as
appropriate.
In the example a STAR at LFBD has
been selected. A WINDOW CSTR
exists at MARRE, requiring it to be
crossed between FL240 and FL200.
Upper and lower altitude limits are
displayed on VERT REV page at
associated WPT.
Since these CSTRs can only be
entered as part of a SID or STAR
procedure stored in NAV data base,
they are in magenta, small font.
ND shows upper and lower limits
(magenta), if CSTR p/b pushed on
EFIS control panel.
These constraints may be modified
only by replacing with a CSTR AT, AT
OR ABOVE or AT OR BELOW.
VERT REV AT MARRE
EFOB=5.4 EXTRA=4.2
CLB SPD LIM UTC CSTR
250/FL100 [ ]
SPD CSTR ALT CSTR
[ ] FL240-FL200
ACCESS
<WIND DATA STEP ALTS>
<RETURN
THV001 {}
UTC SPD/ALT
LMG 1406 .79/ FL324
LMG4 39
MARRE 1412 293/*FL202
LMG4 TRK235° 8
CHALA 1413 " /*FL162
(SPD) 10
(LIM) 1414 *250/ FL100
LMG4 9NM
BD002 1416 " / FL67
DEST UTC DIST EFOB
LFBD23 1425 252 5.3
£$
J43126AA 00
