Thales FMGS - Color Coding; COMPUTED and DATABASE Prompts; Title Page

42
MULTIPHASE
LATERAL F-PLN management
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
 Title page
− HOLD AT XXX if: pilot
defined, or hold to an
altitude, or hold to a fix.
− COMPUTED HOLD AT XXX
if a COMPUTED hold is
selected,
− DATABASE HOLD AT XXX
id a DATABASE hold is
selected,
 Color coding:
− Title is white when hold is
entered in ACTIVE F-PLN,
yellow during selection
(TMPY F-PLN activation).
− Hold parameters are blue
when hold is entered in
ACTIVE F-PLN, yellow
during selection.
 COMPUTED and DATABASE
prompts
COMPUTED prompt [1R]
When pressed, FMGC creates
a TMPY F-PLN and loads a
computed holding pattern, at the revise
waypoint, based on displayed parameters.
Fields are defaulted to FMS values shown
in small font. If overwritten, hold reverts
to a HOLD AT.
If conditions for COMPUTED hold insertion
are not satisfied, arrow is not displayed.
DATABASE prompt [2R]
When pressed, FMGC creates a TMPY F-
PLN and loads a holding pattern, at the
revise waypoint, based on NAVdb
parameters.
Fields are defaulted to NAVdb values
shown in large font. If overwritten, hold
reverts to a HOLD AT.
If DATABASE hold does not exist in the
NAVdb arrow is not displayed.
This prompt is not available when a HOLD
is selected at PPOS.
COMPUTED HOLD AT BIG
INB CRS
319° COMPUTED
TURN
R DATABASE}
TIME/DIST
1.0/3.5
LAST EXIT
UTC FUEL
2231 3.0
TMPY
<F-PLN
DATABASE HOLD AT BIG
INB CRS
319° COMPUTED}
TURN
R DATABASE
TIME/DIST
1.0/3.5
LAST EXIT
UTC FUEL
2231 3.0
<RETURN
DATABSE HOLD
COMPUTED HOLD
HOLD AT BIG
INB CRS
330° COMPUTED}
TURN
R DATABASE}
TIME/DIST
1.0/3.5
LAST EXIT
UTC FUEL
2231 3.0
<RETURN
HOLD AT 7000
INB CRS
145° COMPUTED}
TURN
L DATABASE}
TIME/DIST
1.0/3.5
LAST EXIT
UTC FUEL
---- ---.-
<RETURN
HOLD AT BONTE
INB CRS
178° COMPUTED}
TURN
L DATABASE
TIME/DIST
1.1/4.0
LAST EXIT
UTC FUEL
---- ---.-
<RETURN
HOLD to an altitude
HOLD to a FIX
HOLD AT (Pilot defined)
