Thales FMGS - DIR to Function; General

26
MULTIPHASE
LATERAL F-PLN management
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
3.3. DIR TO function
 General
The following functions are available
by accessing the DIR TO page.
− DIRECT TO [2R]:
The active leg is changed to a direct
track from present position to
selected WPT in [1L].
− ABEAM PTS [3R]:
Function is same as above but
existing WPTs in the ACTIVE F-PLN
between position and DIR TO WPT
are projected onto the DIR TO leg.
− RADIAL IN [4R] - RADIAL OUT
[5R]: a radial from the selected
WPT is intercepted and tracked
inbound to (radial in) or outbound
from (radial out) that WPT.
Depending on option selected in AMI
file, field [3R] or [2R] of DIR TO page
is defaulted yellow for direct access to
ABEAM PTS (option 1) or DIRECT TO
(option 2) function.
When a WPT is inserted in field [1L] a
TMPY F-PLN is created, DIR TO title
page becomes yellow; F-PLN page, if
selected on opposite side, is titled
TMPY (yellow).
Multiple revisions on TMPY F-PLN are
not allowed when DIR TO is selected,
which must be inserted before any
other revision.
If another revision is attempted on the
TMPY F-PLN, “DIR TO IN PROCESS”
s-pad msg (white) is triggered.
DIR TO
WAYPOINT UTC DIST
[ ] ---- ---
F-PLN WPTS
{BOKNO DIRECT TO
WITH
{DEVRO ABEAM PTS
RADIAL IN
{VANAD [ ]°
RADIAL OUT
{VADOM [ ]°
£$
DIR TO
WAYPOINT UTC DIST
VADOM 1549 189
F-PLN WPTS
{BOKNO DIRECT TO }
WITH
{DEVRO ABEAM PTS
RADIAL IN
{VANAD 200° }
RADIAL OUT
VADOM [ ]°
DIR TO DIR TO
{ERASE INSERT*
£$
DIR TO
WAYPOINT UTC DIST
VADOM 1549 189
F-PLN WPTS
{BOKNO DIRECT TO
WITH
{DEVRO ABEAM PTS }
RADIAL IN
{VANAD 200° }
RADIAL OUT
VADOM [ ]°
DIR TO DIR TO
{ERASE INSERT*
£$
OPTION 2
FROM TMPY THV001 {}
UTC SPD/ALT
T-P 1523 / FL360
BRG009° 67
(ABEAM PTS)
VADOM 1549 " / "
UN874 27
BAMES 1553 " / "
UT191 17NM
PODEM 1555 " / "
DIR TO DIR TO
{ERASE INSERT*
£$
