Thales FMGS - Ils Crs [4 L]; Ils;Freq [3 L]

MULTI PHASE
26 NAVIGATION management & monitoring
 ILS/FREQ [3L]
Compatible navaid types for this field
are: ILS, ILS TAC, ILS DME, LOC.
Ident, frequency and course are
automatically tuned if ILS is associated
with DEP RWY or DEST RWY.
If no ILS is auto-tuned or manually
tuned, brackets are displayed.
RADIO NAV
VOR1/FREQ FREQ/VOR2
CHW/115.20 115.20/CHW
CRS CRS
[ ] [ ]
ILS /FREQ CHAN/ MLS
IRR/110.30 [ ]/[ ]
CRS SLOPE CRS
F273 -.- [ ]
ADF1/FREQ FREQ/ADF2
[ ]/[ .] [ .]/[ ]

ILS CRS [4L]
If an ILS is tuned (manually or
automatically) the course is automatically
entered preceded by "F" (for Front beam)
or "B" (for Back beam).
BACK BEAM option is available if
activated in OPC file.
If no course is entered four amber boxes
are displayed, a course can be entered
manually.
If no ILS is tuned, brackets are
displayed; no entry is allowed.
When a course is displayed (entered
manually or automatically), it can be
modified. Only manually entered courses
can be cleared.
RADIO NAV
VOR1/FREQ FREQ/VOR2
BPT/114.50 114.50/BPT
CRS CRS
[ ] [ ]
ILS /FREQ CHAN/ MLS
IBPT/109.50 [ ]/[ ]
CRS SLOPE CRS
B296 -.- [ ]
ADF1/FREQ FREQ/ADF2
BP/257.0 257.0/BP
{ADF1 BFO ADF2 BFO}
RADIO NAV
VOR1/FREQ FREQ/VOR2
TOU/117.70 117.70/TOU
CRS CRS
[ ] [ ]
ILS /FREQ CHAN/ MLS
[ ]/110.60 [ ]/[ ]
CRS SLOPE CRS
____ -.- [ ]
ADF1/FREQ FREQ/ADF2
[ ]/[ .] [ .]/[ ]
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
