MULTI PHASE
NAVIGATION management & monitoring 15
PILOTS RUNWAYS [3R]
Enables creation, review and deletion of
pilot-defined RUNWAYS.
From DATA 2/2 page:
PILOTS RUNWAYS [3R]..........
...................................... Press
Logic for display is same as PILOT
WAYPOINTS: if no PILOTS RUNWAY
exists, NEW RUNWAY page is displayed;
otherwise the first stored runway in the
list is displayed.
To create a RUNWAY:
If NEW RUNWAY page is not shown
NEW RUNWAY [5R]....... Press
RUNWAY may be created by entering:
NEW RUNWAY
IDENT
________
LAT/LONG
____.__/_____.__
LENGTH
____
ELV
____ RETURN>
CRS
___
STORED RUNWAY 1/1
IDENT ILS IDENT
ABCD36 XYZ
LAT/LONG
4500.0N/00000.0E
LENGTH
3600M
ELV NEW
450 RUNWAY>
CRS
000° DELETE ALL}
− IDENT [1L] up to 7 letters and/or
digits are available for designation,
− All boxed data fields as required.
If ten RUNWAYS have already been stored and NEW RUNWAY prompt
is pressed, "LIST OF 10 IN USE" s-pad msg (white) is triggered.
Logic for deletion of stored runways, all or individually and associated
scratchpad messages is identical to stored waypoints.
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
