APPENDICES
MCDU NAMING and DATA FORMAT 3
This chapter provides information on the following:
− Waypoint label and abbreviations: NAV data base WPTs, Pilot created
WPTs, Pseudo WPTs,
− Flight Plan Markers,
− Lateral defining legs,
− MCDU prompts,
− DATA FORMAT.
2.1. Waypoint abbreviations

NAV data base WPTs
NAV data base files are encoded and released by Thales based on data
from the operator's provider.
NAV data base codification must be compliant with the ARINC 424
specification.
Waypoint naming and procedures construction may differ from one
provider to another. In some cases strict adherence to Authority
definition is not compatible with FMS stringing rules and may be at
discretion of data provider.
The example below shows DEP LFBO and ARR EGLL with two different
providers.
FROM THV001 {}
FIST5A TIME SPD/ALT
LFBO14R 0000 141/ 490
C144° BRG144° 1
1000 0000 153/ 1000
C144° TRK142° 4
TOU8&} 0002 250/ 3130
TOU144 2
4000 } 0002 " / 4000
C311° 7NM
INTCPT 0004 " / FL88
DEST TIME DIST EFOB
EGLL27R 0121 543 4.5
£$
FROM THV001 {}
FIST5A TIME SPD/ALT
LFBO14R 0000 141/ 490
HC144° BRG144° 1
900 0000 153/ 900
C144° TRK144° 4
D144H} 0002 " / *3130
C356° 8
TOU 0005 250/ FL85
(SPD) 3NM
(LIM) 0005 *250/ FL100
DEST TIME DIST EFOB
EGLL27R 0122 532 4.4
£$
THV001 {}
BIG3B TIME SPD/ALT
BIG 0115 250/ 5390
BIG 8
BIG80 0116 " / 2770
TRK289° 0
(DECEL) 0117 250/ 2660
C273° 6
IRR75 0118 138/ *2660
C273° 3-3.0°
IRR4 0119 " / 1390
DEST TIME DIST EFOB
EGLL27R 0121 543 4.5
£$
THV001 {}
BIG3B TIME SPD/ALT
BIG 0115 *220/ *FL64
C335 7
BIG07& 0117 " / *2500
TRK295° 1
(DECEL) 0117 220/ 2500
C273° 6
C127R 0119 138/ *2500
C273° 3-3.0°
FI27R 0120 " / 1400
DEST TIME DIST EFOB
EGLL27R 0122 532 4.4
£$
