FLIGHT PHASES
PREFLIGHT 17
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
 Complete F-PLN page
F-PLN key...................... Press
Convention:
LAT REV (lateral revision) indicates an
action on a Left Select Key. VERT REV
(vertical revision) indicates an action on
a Right Select Key.
 Enter Departure
This procedure is applicable to enter a
departure (RWY & SID), or to change the
defaulted RWY & SID if included in CO
RTE:
LAT REV at origin [1L]... Press
DEPARTURE [1L] ........... Press
The MCDU displays the runway available
in the NAVdb with the following
information: length, and if available ILS
(course, ident, frequency).
 DEPARTURE pages
DEPARTURE pages have two displays:
RWY(s)
If vertical arrows are showed at the right
bottom of the screen, use vertical slew
keys to display all RWYs available in the
NAVdb.
SID(s)
Access to this data is by using the
horizontal slew keys.
The same logic as above is applicable if
vertical arrows are displayed.
RWY ...................Select/Press
Select runway and press corresponding
LSK.
Ex: 14R.
Use vertical slew keys when necessary.
The MCDU display switches to SIDs
pages and changes TITLE FIELD in yellow
with TMPY F-PLN at the bottom left.
FROM THV001{}
TIME SPD/ALT
LFBO ---- ---/ 500
---F-PLN DISCONTINUITY--
EGLL ---- ---/ 130
------END OF F-PLN------
EGLL ---- ---/ 80
DEST TIME DIST EFOB
EGLL ---- 476 -----
£$
LAT REV FROM LFBO
43°38.1N/001°22.1E
<DEPARTURE
NEXT WPT
[ ]
NEW DEST
[ ]
<RETURN
DEPARTURE FROM LFBO {}
RWY SID TRANS
--- ------ ------
AVAILABLE RUNWAYS
{14L 3000M CRS144
ILS TG/108.90
{14R 3500M CRS144
ILS TBS/110.70
{32L 3500M CRS324
ILS TBN/109.30
{32R 3000M CRS324
ILS TD/108.35
<RETURN END
DEPARTURE FROM LFBO {}
RWY SID TRANS
14R ------ ------
SIDS AVAILABLE TRANS
{AFRI5A
{AFRI5H
{AMOL5A
{AMOL5H
TMPY EOSID
<F-PLN NONE
£
