Thales FMGS - Navaid [2 L]

MULTI PHASE
6 NAVIGATION management & monitoring
 NAVAID [2L]
Enables display of navaid
definition data as contained in
NAVdb or in pilot-stored navaid
list.
From DATA page 2/2:
NAVAID [2L] ........... Press
Navaid page is displayed with
amber boxes In [1L].
IDENT[1L]............... Enter
Ident may be any NAVdb or pilot
stored navaid.
Examples shown in this page
and next are:
Ex 1: LON (VOR DME)
Ex 2: TS (ADF)
Ex 3: CV (LOC)
Ex 4: TBS (ILS DME NON-
COLLOCATED)
Ex 5: MTBS (MLS)
CLASS of navaid [2L] may be
any of the following:
VOR, DME, LOC, ILS, NDB, ILS
DME, ILS TAC, VOR TAC, VOR
DME, MLS,MLS DME, TACAN.
Non-collocated VOR DME, VOR
TAC, ILS DME or MLS DME, ILS
TAC is written according to
navaid installation.
ILS category 0 is displayed as
LOC.
LAT/LONG [3L].
If a non-collocated VOR DME or
VORTAC is displayed, LAT/LONG i
LAT/LONG for ILS, I
s VOR LAT/LONG.
LS DME or ILS TAC is LAT/LONG of localizer.
REQ or CHAN
LAT/LONG for MLS, MLS DME is LAT/LONG of azimuth antenna.
F
NAVAID
IDENT
_______
Ex. 1
NAVAID
IDENT STATION DEC
LON 003W
CLASS
VORDME
LAT/LONG
5129.2N/00028.0W
FREQ
113.60
ELV
110
FIG OF MERIT
2 (130NM)
LON
Ex. 2
NAVAID
IDENT
TS
CLASS
NDB
LAT/LONG
4330.2N/00129.2E
FREQ
423.0
NAVAID
IDENT RWY IDENT
CV LFKC18
CLASS
LOC
LAT/LONG COURSE
4231.1N/00847.6E 180°
FREQ
109.50
ELV
0
Ex. 3
[4L]. Frequency for ILS, CHAN for MLS.
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
