MULTI PHASE
NAVIGATION management & monitoring 19
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
tem
DUPLICATE NAMES
38NM LAT/LONG FREQ
*AMB 45N/000E
120NM
*AMB 47N/001E 341.0
121NM
*AMB 47N/001E 113.70
5001NM
*AMB 01S/078W 360.0
6113NM
*AMB 33S/070W 116.10
<RETURN
£
All items with same IDENTs existing
in NAVdb and Pilot stored data are
listed in order of increasing distance
from PPOS (nearest first).
If more than five items exist, arrow is
displayed bottom right; use vertical
slew keys for scroll.
Items are identified by:
− Distance from PPOS, shown left of
label line,
If A/C position is invalid, dashes
are displayed,
DUPLICATE NAMES
139NM LAT/LONG
*N45W022 4525.2/00212.5
*N45W022 4552.6/00236.1
<RETURN
− Coordinates, in degrees rounded
down.
Example: waypoint
45°51.5N/000°12.6E gives
45N/000E.
Lat/Long stored WPTs with ident
over 7 characters (OPC option)
may generate a non-unique
identifier as a Lat/Long pilot stored
WPT. In that case, the WPT ident is
displayed and the complete
Lat/Long without N/S, E/W. See
example shown here.
DUPLICATE NAMES
38NM LAT/LONG FREQ
*AMB 45N/000E
120NM
*AMB 47N/001E 341.0
121NM
*AMB 47N/001E 113.70
5001NM
*AMB 01S/078W 360.0
6113NM
*AMB 33S/070W 116.10
<RETURN
£
− FREQ, which is displayed if the i
is a navaid.
When the selection is made, adjacent
left LSK is pressed, MCDU reverts to
TMPY F-PLN reflecting the entered
revision.
In the example, AMB VORDME freq.
113.70 is selected.
FROM THV001 {}
UTC SPD/ALT
T-P 1516 / FL358
BRG357° 68
ADABI 1532 .79/ FL360
TRK026° 56
AMB 1540 " / "
---F-PLN DISCONTINUITY--
BOKNO 1544 .79/ "
TMPY TMPY
{ERASE INSERT*
£$
