FLIGHT PHASES
DESCENT 17
 If OP DES mode is selected constraints are ignored:
On ND:
A white circle is displayed around the WPT.
On MCDU F-PLN page:
Star is amber or magenta depending on predicted
passing altitude.
FMA:
If the FCU selected altitude is
lower than the constraint
altitude ALT armed and
target altitude are displayed
in magenta.
Caution
TIGER
FL15O
MTMMM
=
POM
=
J==fUMM=
MTMMM
=
AP1
1FD2
A/THR
MDA 278
SPEED
HDG
V/S -1
ALT
800
DES
ALT
AP1
1FD2
A/THR
MDA 278
NAV THR IDLE
If HDG mode is selected,
DES mode disengages,
- FMGS reverts to V/S,
- Constraints are
ignored.
