FLIGHT PHASES
APPROACH 29
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
TMPY F-PLN [6L]........... Press
ND Check
TMPY INSERT [6R] ........ Press
Check TO WPT
 If A/C is not on correct HDG:
HDG/TRK ......... Select/Adjust
Otherwise "SELECT HDG/TRK FIRST" s-pad msg (white) is triggered.
 If APP modes already armed or engaged,
they revert to HDG – V/S.
APP mode......................Select
Select as required.
ARRIVAL TO EGLL {}
APPR VIA STAR
ILS27L NONE NONE
APPR TRANS
<VIAS NONE
STARS AVAILABLE TRANS
{WLD3D
NO STAR
TMPY
<F-PLN
$
TMPY THV001 {}
UTC SPD/ALT
---F-PLN DISCONTINUITY--
CI27L 2355 137/ *2380
C273° TRK273° 3-3.0°
FI27L 2357 " / 1400
C273° 4-3.0°
EGLL27L
&2358
137/ 130
C273° 2NM
1080 { ---- ---/ -----
TMPY TMPY
{ERASE INSERT*
£$
THV001 {}
UTC SPD/ALT
---F-PLN DISCONTINUITY--
CI27L 2356 137/ *2380
C273° TRK273° 3-3.0°
FI27L 2357 " / 1400
C273° 4-3.0°
EGLL27L
&2359
137/ 130
C273° 2NM
1080 { ---- ---/ -----
DEST UTC DIST EFOB
EGLL27L 2359 12 3.9
£$
