MULTIPHASE
6 F-PLN pages
LAT REV
From F-PLN pages A or B, pressing Left LSKs enable access to LATERAL
REVISIONS pages (LAT REV) to make lateral revisions in F-PLN.
Pressing Right LSKs enable access to VERTICAL REVISIONS.
LAT REV is not available from:
− Pseudo waypoints,
− F-PLN markers, except F-PLN DISCONTINUITY.
LAT/LONG of the revise point is displayed in line 2 if the revise point is
a fixed waypoint (not displayed if the revise point is a F-PLN
DISCONTINUITY or PPOS).
Lateral Revision functions applied to SECONDARY F-PLN are accessed
similarly from SEC F-PLN pages.
LAT REV FROM PPOS
− Access to OFFSET page via [2L] prompt,
− Access to HOLD page via [3L].
LAT REV FROM other WPT
− Access to HOLD page via [3L],
− Access to ENABLE ALTN function via [4L],
− Access to AIRWAYS page via [5R],
This prompt is not available from LAT/LONG, PLACE/BRG/DIST,
PLACE-BRG/PLACE-BRG,Along Track Offset, Abeam waypoints.
− NEXT WPT [3R], NEW DEST [4R] enable direct F-PLN revisions.
LAT REV FROM DEST
− Access to ALTN page via [3L],
− Access to ENABLE ALTN function via [4L],
− Access to ARRIVAL pages via [1R],
− NEXT WPT [3R] enable direct F-PLN revisions.
LAT REV FROM DISCON
When a LAT REV at a F-PLN
DISCONTINUITY is selected, NEXT WPT
[3R] and NEW DEST [4R] are only
available.
Lateral functions are described in Ch 3.
LAT REV FROM DISCON
ARRIVAL>
NEXT WPT
[ ]
NEXT DEW
[ ]
<RETURN
J43126AA 00
© THALES AVIONICS S.A.
AIRBUS A318/319/320/321
