Thales FMGS - Page 313

MULTIPHASE
F-PLN pages 11
When a revision is made F-PLN page
title becomes TMPY and entire F-PLN
including ALTN is displayed in yellow
with associated predictions.
DEST information is no more displayed
but may be accessed by scrolling.
Ex: Waypoint TUNBY is inserted after
TIGER
ND.................................Check
Check for consistency with the desired
revision.
TMPY ERASE [6L] .......... Press
To erase the entered revision,
Or
TMPY INSERT [6R] ........ Press
To activate the entered revision.
If a second or more revisions are
made, TMPY ERASE prompt is replaced
by
ONCE UNDO / THEN ERASE prompt.
This function enables to delete the last
entered revision.
Ex: Waypoint ACORN is inserted after
TUNBY. Pressing ONCE UNDO returns
to the previous state
FROM TMPY THV001 {}
UTC SPD/ALT
T-P 1522 / FL356
BRG333° 70
TIGER 1534 293/*FL154
TRK328° 7
TUNBY 1535 " / FL117
(SPD)
(LIM) 1536 *250/ FL100
ACORN 1536 " / FL92
ONCE THEN
{UNDO/ERASE INSERT*
£$
FROM TMPY THV001 {}
UTC SPD/ALT
T-P 1522 / FL356
BRG333° 70
TIGER 1534 293/*FL154
TRK328° 7
TUNBY 1535 " / FL117
---F-PLN DISCONTINUITY--
(SPD)
(LIM) 1536 *250/ FL100
TMPY TMPY
{ERASE INSERT*
£$
FROM THV001 {}
UTC SPD/ALT
T-P 2051 / FL356
BRG331° 15
TIGER 2101 293/*FL154
(SPD) TRK319° 9
(LIM) 2102 *250/ FL100
BIG3B 1
D139L 2103 *250/ FL105
BIG3B 12NM
BIG 2105 *220/ 4780
DEST UTC DIST EFOB
EGLL27R 2114 58 4.1
£$
FROM TMPY THV001 {}
UTC SPD/ALT
T-P 1522 / FL356
BRG333° 70
TIGER 1533 293/*FL154
TRK328° 7
TUNBY 1534 " / FL117
---F-PLN DISCONTINUITY--
(SPD)
(LIM) 1535 *250/ FL100
TMPY TMPY
{ERASE INSERT*
£$
