Thales FMGS - Page 315

MULTIPHASE
F-PLN pages 13
Multiple revisions are not permitted while a DIR TO revision is pending
and generates "DIR TO IN PROCESS" s-pad msg.
In the example below a DIR TO BIG has been selected and CLR of
BIG07 is attempted on the other MCDU.
Examples of TMPY F-PLN are given through out this manual
DIR TO
WAYPOINT UTC DIST
[ ] ---- ---
F-PLN WPTS
{D139L DIRECT TO
WITH
{BIG ABEAM PTS
RADIAL IN
{BIG07 [ ]°
RADIAL OUT
{CI27R [ ]°
£$
DIR TO
WAYPOINT UTC DIST
BIG 2158 36
F-PLN WPTS
{D139L DIRECT TO }
WITH
BIG ABEAM PTS
RADIAL IN
{BIG07 137° }
RADIAL OUT
{CI27R [ ]°
DIR TO DIR TO
{ERASE INSERT*
£$
TMPY THV001 {}
UTC SPD/ALT
(ABEAM PTS)
BIG 2208 *220/ 3980
TRK336° 5
(DECEL) 2209 220/ 2500
C335 2
BIG07@ 2210 137/ *2500
C273° 7NM
CI27R 2213 " / *2500
DIR TO DIR TO
{ERASE INSERT*
CLR £$
TMPY THV001 {}
UTC SPD/ALT
(ABEAM PTS)
BIG 2208 *220/ 3980
TRK336° 5
(DECEL) 2209 220/ 2500
C335 2
BIG07@ 2210 137/ *2500
C273° 7NM
CI27R 2213 " / *2500
DIR TO DIR TO
{ERASE INSERT*
DIR TO IN PROCESS £$
