MULTI PHASE
10 SEC F-PLN
SEC INIT {}
CO RTE FROM/TO
[ ] [ ]/[ ]
ALTN/CO RTE INIT
----/---------- REQUEST*
FLT NBR
[ ]
LAT LONG
----.-- -----.--
COST INDEX
--- WIND>
CRZ FL/TEMP TROPO
----- /---° 36090
Complete SEC INIT A and B as described
in Part II: Flight phases.
In the example a RTE EGLL/EGCC is
prepared.
INIT REQUEST field [2R] is displayed if
DATALINK option is selected in OPC file;
star is displayed if data-link transmission
is available.
See Part III: Ch 9 Data link.
SEC F-PLN key ..........Press
SEC F-PLN [2L] .........Press
SEC F-PLN page A is
displayed.
Enter route as required.
Predictions are available if
valid data have been entered
in SEC INIT page B.
SEC INIT {}
TAXI ZFWCG/ ZFW
0.2 25.0/ [ .]
TRIP/TIME BLOCK
---.-/---- [ .]
RTE RSV/%
---.-/ 5.0
ALTN/TIME TOW
---.-/---- ---.-
FINAL/TIME LW
---.-/0030 ---.-
EXTRA/TIME
---.-/----
SEC INIT {}
CO RTE FROM/TO
NONE EGLL/EGCC
ALTN/CO RTE INIT
NONE/ REQUEST*
FLT NBR
THV001
LAT LONG
5128.6N 00027.7W
COST INDEX
30 WIND>
CRZ FL/TEMP TROPO
FL150 / -15° 36090
SEC INDEX
{COPY ACTIVE
<SEC F-PLN PERF>
{DELETE SEC
*ACTIVATE SEC
SEC F-PLN
PRINT*
FROM SEC {}
UTC SPD/ALT
EGLL 1653 ---/ 80
---F-PLN DISCONTINUITY--
(SPD)
(LIM) 1656 *250/ FL100
118
(T/C) 1721 338/ FL150
47NM
(T/D) 1727 326/ FL150
DEST UTC DIST EFOB
EGCC 1740 131 0.4
£$
J43126AA 00
