Thales FMGS - Page 472

MULTI PHASE
24 NAVIGATION management & monitoring
RADIO NAV
VOR1/FREQ FREQ/VOR2
LON/113.60 113.60/LON
CRS CRS
[ ] [ ]
ILS /FREQ CHAN/ MLS
[ ]/[ .] [ ]/[ ]
CRS SLOPE CRS
[ ]/ -.- [ ]
ADF1/FREQ FREQ/ADF2
[ ]/[ .] [ .]/[ ]
AMB
DUPLICATE NAMES
227NM LAT/LONG FREQ
*AMB 47N/001E 113.70
4087NM
*AMB 67N/157W 116.10
6074NM
*AMB 33S/070W 116.10
9118NM
*AMB 27S/152E 114.70
<RETURN
RADIO NAV
VOR1/FREQ FREQ/VOR2
LON/113.60 113.60/LON
CRS CRS
[ ] [ ]
ILS /FREQ CHAN/ MLS
[ ] [ .] [ ]/[ ]
CRS OPE CRS SL
[ ]/ -.- [ ]
ADF1/FR FREQ/ADF2EQ
[ ]/[ .]/[ ] .] [
AMB1
NEW NAVAID
IDENT
AMB1NA
CLASS
______
LAT/LONG
____.__/____.__
RETURN>
If more than one navaid in
NAVdb have the same
ident, DUPLICATE NAMES
page is displayed.
See 7.1 in this chapter.
If the ident is not in the
NAVdb, NEW NAVAID page
is displayed.
See 7.1 in this chapter.
If no VOR, VORDME or
VORTAC is found, only the
frequency is displayed and
brackets are displayed in
ident field; "NOT IN DATA
BASE" s-pad msg (white) is
triggered. ND shows
frequency only.
RADIO NAV
VOR1/FREQ FREQ/VOR2
[ ]/113.70 115.10/BIG
CRS CRS
[ ] [ ]
ILS /FREQ CHAN/ MLS
[ ]/[ .] [ ]/[ ]
CRS SLOPE CRS
[ ] -.- [ ]
ADF1/FREQ FREQ/ADF2
[ ]/[ .] [ .]/[ ]
NOT IN DATA BASE
VOR1
113.7O
M
--- NM
J43126AA 00
