MULTI PHASE
NAVIGATION management & monitoring 37
In PRE-FLIGHT or TAKE OFF phase.
If the take off runway associated with a MLS has been selected, the
entry is compared with it:
− If they are same, no message is displayed. The nominal azimuth of
the entered MLS is auto-tuned and displayed in [4R]; dashes are
displayed for slope.
− If they are not same, "RWY/LS MISMATCH" s-pad msg (amber) is
triggered. The nominal azimuth of the entered MLS is auto-tuned
and displayed in [4R]; dashes are displayed for slope.
If the take off runway associated with an ILS has been selected,
"RWY/LS MISMATCH" s-pad msg (amber) is triggered. The nominal
azimuth of the entered MLS is auto-tuned and displayed in [4R];
dashes are displayed for slope.
If no LS (ILS or MLS) has been selected at the origin runway, no
message is displayed. The nominal azimuth of the entered MLS is auto-
tuned and displayed in [4R]; dashes are displayed for slope.
AIRBUS A318/319/320/321
© THALES AVIONICS S.A.
J43126AA 00
