Thales FMGS - Page 538

MULTIPHASE
24 DATA LINK
Screens shown are examples.
[1L] TOW/TOCG field
Reference Take-off Gross Weight and
Take-Off Center of Gravity.
[2L] TEMP/QNH field
UPLINK MAX TO DATA 1/4{}
TOW /TOCG SHIFT/
RWY
65.6/26.0 14R
TEMP/QNH V1 TO LIMIT
18°/1019 132
MAG WIND VR FLAPS/THS
140°/010 141 2/UP0.6
CONTAM V2
WET 144 FLEX TO>
THR RED/ACC ENG OUT ACC
1990
UPLINK INSERT
<TO DATA UPLINK*
− For UPLINK MAX TO DATA pages, label
line displays TEMP/QNH or TEMP/QFE;
data line displays uplinked Max
Temperature and uplinked Baro
Setting.
− For UPLINK FLX TO DATA pages, label
line displays FLX/QNH or FLX/QFE;
data line displays uplinked Flex
Temperature and uplinked Baro
Setting.
UPLINK MAX TO DATA 2/4{}
TOW /TOCG SHIFT/
RWY
--.-/--.- ----/------
TEMP/QNH V1 TO LIMIT
---°/----- --- ----
MAG WIND VR FLAPS/THS
---°/--- --- -/-----
CONTAM V2
--------- --- DRT TO>
THR RED/ACC ENG OUT ACC
-----/----- -----
UPLINK
<TO DATA
− For UPLINK DRT TO DATA pages (if
Derated Take-off option activated),
label line displays DRT/QNH or
DRT/QFE; data line displays uplinked
Alternate Thrust Rating shown in DXX
format uplinked Baro Setting.
If no data is available, blanks are
displayed for the corresponding field(s).
QNH/QFE:
The units are determined by the setting
on EFIS Control Panel 1 at the time the
uplink is processed.
If EFIS Control Panel 1 is invalid (e.g. in
single or independent modes on FMS2),
the unit follows the feet/meters OPC
option. No update is performed if the
selected unit or reference system on the
EFIS Control Panel 1 is changed.
Label line shows QNH or QFE as
appropriate to uplinked baro setting. If
no valid baro setting is entered, label line
shows QNH.
UPLINK FLX TO DATA 2/4{}
TOW /TOCG SHIFT/
RWY
65.6/26.0 14R
FLX/QNH V1 TO LIMIT
+35°/1019 135
MAG WIND VR FLAPS/THS
140/010 145 2/UP0.6
CONTAM V2
WET 148 MAX TO>
THR RED/ACC ENG OUT ACC
1990
UPLINK INSERT
<TO DATA UPLINK*
UPLINK DRT TO DATA 1/4{}
TOW /TOCG SHIFT/
RWY
65.6/26.0 14L
DRT/QNH V1 TO LIMIT
D08/1019 135
MAG WIND VR FLAPS/THS
140/010 145 2/UP0.6
CONTAM V2
WET 148 MAX TO>
THR RED/ACC ENG OUT ACC
1990
UPLINK INSERT
<TO DATA UPLINK*
