Thales FMGS - Page 645

To Next Page

To Previous Page

APPENDICES

MESSAGES 19

TYPE

COLOR

EFIS

TO GA APP Disp.

DATA LINK

SCRATCHPAD

MESSAGE

DEFINITION

Nbr

WIND DATA UPLINK

II W D Valid up-linked wind data are available for

review in either flight plan.

112

WIND UPLINK

EXISTS

I W Y D A flight plan modification (ACTIVE or SEC) is

attempted while uplink winds are not yet

inserted.

115

XXXX IS

DESELECTED

I W Y XXXX: NAME OF NAVAID or NUMBER of a

SATELLITE

Pilot attempts to deselect a navaid or a

satellite, which is already de-selected.
