148
ANALYZING TOMOGRAMS
To reset a single color channel, click underneath the slider control bar. To reset all
color channels, click at the bottom of the screen.
If the fundus is not photographed on condition that a check mark is placed for "Use FDS format for
Color fundus photography" on the "Fundus photography" tab of "OCTSet" (refer to "[Fundus pho-
tography] tab" on P.xxx), the fundus photography data cannot be analyzed. The fundus data cap-
tured by OCT photography can be analyzed even if a check mark is not placed for "Use FDS
format for Color fundus photography".
4.4.2. A variety of measurement
Use the Measure Tool to make desired measurements as shown below:
•Line
Select "Line" from "Measure Tool". Click the left mouse button at the start point of the distance to be mea-
sured, and drag it to the end point.
You can measure up to 8 places.
•Area
Select "Area" from "Measure Tool". Click the left mouse button at the start point and drag it to surround
the range to be measured. If the start point does not overlap the end point, they are automatically linked
by a line to surround the above range.
You can measure up to 8 places.
To Next Page
