52
CAPTURING TOMOGRAMS
2.6.9. Setting
Shift to the grabber setting screen of the "Fundus photography" tab in "OCTSet.exe" (OCT Configuration).
You can set a variety of data about the fundus grabber. For starting "OCTSet", refer to "11.3. A VARIETY
OF SETTING" on P.217.
(1) Image Directory
Specify a directory to save the image log file temporarily.
"Secondary" is a spare area when the "Primary" capacity is full.
It is possible to use the folder selection dialog box with the [Browse...] button and specify the
directory. Be careful not to specify the same drive for "Primary" and "Secondary".
(2) Log Directory
Specify a directory to save the photography log file temporarily.
It is possible to use the folder selection dialog box with the [Browse...] button and specify the directory.
(3) Show patient select window when capture is finished.
Set whether the "FastMap" capture mode should be finished and the patient selection list should be dis-
played when finishing fundus photography to close the window.
Place a mark in the check box. This item is validated and the patient selection list is displayed.
(4) Thumbnail Selection Style
Set the thumbnail selection method in the "ALL IMAGES" tab.
IMAGEnet style: Two or more thumbnails can be selected by single-click.
As pressing the [Ctrl] key, click the button. The selected status is reversed.
Windows style: As pressing the [Ctrl] key, click the button. Two or more thumbnails can be
selected.
As pressing the [Shift] key, click the button. The thumbnails in the selection range
can be selected at a time.
(1)
(2)
(6)
(7)
(8) (4)
(5)
(10)
(3)
(9)
To Next Page
