Xerox WorkCentre 5230

February, 2008
2-90
WorkCentre 5225, 5230
005-942
Launch Version
Status Indicator Raps
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB (PL 15.3) P786-1 (+) and GND (-) (BSD 5.2
Flag 5).
The voltage is approx. +24VDC.
YN
Replace the DADF PWB (PL 15.3).
Replace the DADF Nudger Motor (PL 15.6). If the problem persists, replace the DADF
PWB (PL 15.3).
Replace the DADF PWB (PL 15.3).
A
