4-166
WorkCentre 5225, 5230
REP 16.3.4
Launch Version
Repairs and Adjustments
c. Remove the Screw (1). (Figure 2)
d. Remove the Booklet Rear Cover.
Figure 2 Removing the Booklet Rear Cover (j0st41675)
Replacement
1. Reverse the removal procedure for replacement.
Screw
Booklet
Rear Cover
