Xerox WorkCentre 5230 User Manual

February, 2008
3-12
WorkCentre 5225, 5230
Launch Version
Image Quality
Figure 2 Standard Test Pattern (Side B)(j0st3202)
Output Reference Guide, SIR542.00
Procedure
This test document serves as a reference guide for measuring the solid area density of the Side A copies of the test pattern,
82P524 and 82P521 (Figure 3).
Figure 3 Output Reference Guide, SIR542.00 (j0st3203)

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
